【Upgrade】 Portable Wrist CCTV Tester,5'' LCD Monitor,HDMI in &VGA in,Camera Debugging Helper
4.7 (141 items)
Limited Time Sale$56.99 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 209173007 | Release Date | 2026/03/29 | List Price | $38.00 | Model Number | 209173007 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【CCTV TESTER】5-inch 800X480 Resolution Screen PAL/NTSC (Auto adapt). CCTV Tester ,Hybrid camera tester is able to test and debug coaxial 720P / 960P / 1080P /3MP/4MP/5MP/8MP AHD camera &CVI camera & TVI camera and traditional CVBS analog camera （Does not support IP & SDI cameras).
- 【PTZ CONTROL】Support RS485 ,Compatible with multiple PTZ protocols (PELCO-D / PELCO-P ); baud rate: 2400, 4800, 9600, 19200 (optional), zooms in/out the lens, adjusts the focus, aperture/sets，PTZ continuing rotate test.
- 【UTC CONTROL】Press and hold the M menu button for 5 seconds to enter, UTC is displayed at the top of the screen. Press the menu button to bring up the camera menu and operate the UTC menu with the up / down / left / right input keys. Press the M menu button for 5 seconds to exit UTC mode.
- 【HDMI &VGA input】support resolution (800*600 , 1024*768 , 1280*720 , 1280*1024 , 1440*900 , 1920*1080 ) 60HZ.
- 【APPLICATION 】 UTP cable test: Test UTP cable connection status and display on the screen(BNC cable&LAN cable).Audio test, Supports 12 languages to choose from ,USB2.0 interface provides 5V / 1A emergency power output,Power the camera with DC 12V /1A power output from the tester.
| UPC | 791759542414 |
|---|---|
| Brand | SGEF |
| Color | Black |
| Autofocus | No |
| ISO Range | 100-6400 |
| Zoom Type | Optical Zoom |
| Focus Type | Manual Focus |
| File Format | JPEG, MP4 |
| Item Weight | 1.1 Pounds |
| Screen Size | 5 Inches |
| Sensor Type | CMOS |
| Aspect Ratio | 1.66:1 |
| Camera Flash | No Flash |
| Manufacturer | SGEF |
| Has SelfTimer | No |
| Aperture Modes | manual |
| Shooting Modes | Manual |
| Audio Recording | No |
| Viewfinder Type | LCD screen |
| Maximum Aperture | 2.8 f |
| Audio Output Type | HDMI |
| Light Sensitivity | 100-6400 |
| Compatible Devices | Desktop, Laptop, Smartphone, Tablet, Television |
| Hardware Interface | AV Port |
| Video Capture Format | H.264, H.265, MJPEG |
| Exposure Control Type | Manual |
| Water Resistance Level | Not Water Resistant |
| Connectivity Technology | HDMI, VGA |
| Video Capture Resolution | 5MP, 8MP |
| Effective Still Resolution | 8 MP |
