Transistor Tester, Transistor Capacitor Tester, SMD-Electronic Component Tester, Diode Triode Zener Diode Resistance Inductance Battery Test LCR Meter(ESR02PRO- Black clip)

Features:This meter is a great tool for engineers, electronics repair technicians, and factory operators. It can easily test both plug-in and surface-mount devices, as well as various types of diodes, transistors, and thyristors. It analyzes device type, pin polarity, output HFE, valve voltage, and junction capacitance of FETs.One-touch start and one-touch acquisition.A large LCD display with backlight makes reading easy.It automatically tests component pins and displays them on the LCD.It automatically detects components such as NPN and PNP bipolar transistors, N-channel and P-channel MOSFETs, diodes (including dual diodes), thyristors, transistors, resistors, and capacitors.It can detect transistor emitter forward bias voltage, MOSFET protection diodes, and amplify reference voltage sources.It can measure MOSFET gate threshold voltage and gate capacitance.Specifications:Part Name: ESR02 Pro Electrolytic Transistor TesterMaterial: ABSModel: ESR02 ProResistance: 0Ω~50Ω, Resolution: 0.01 ohmCapacitance: 25pF~100mF, Resolution: 1pFInductance: 0.01mH~20H, Resolution: 0.01mHCapacitance Resolution: 0.01ΩBattery: 1 x 9V 6LR61 battery (not included)Color: Black, Redsize: Approximately 14 x 8 x 4.5cm / 5.5 x 3.1 x 1.8 inchesInstructions:Press the "POWER/TEST" button to power on and begin testing. This button can be used to repeat multiple measurements. The tester automatically shuts off 20 seconds after the measurement is completed.Three sockets are provided, each for pins 1, 2, and 3.The device does not need to be placed in the order described. After the measurement, the screen will display the component function of each pin.The "Typical Electrolytic Capacitor Values" table on the back is for reference only. These values are typical for standard-grade electrolytic capacitors at room temperature.Short test pins 1, 2, and 3 together. Press the "POWER/TEST" button. The screen will prompt you to enter calibration. Press the button again within 2 seconds to confirm. After a few seconds, the screen will prompt you to release pins 1, 2, and 3. Release them and wait for calibration to complete.Package Contents:Package 1:1 x Transistor Tester1 x User ManualPackage 2:1 x Transistor Tester1 x User Manual1 x Test Clip

• This meter is a great tool for engineers, electronics repair technicians, and factory operators. It can easily test both plug-in and surface-mount devices, as well as various types of diodes, transistors, and thyristors. It analyzes device type, pin polarity, output HFE, valve voltage, and junction capacitance of FETs.
• One-touch start and one-touch acquisition.
• A large LCD display with backlight makes reading easy.
• It automatically tests component pins and displays them on the LCD.
• It automatically detects components such as NPN and PNP bipolar transistors, N-channel and P-channel MOSFETs, diodes (including dual diodes), thyristors, transistors, resistors, and capacitors.
• It can detect transistor emitter forward bias voltage, MOSFET protection diodes, and amplify reference voltage sources.
• It can measure MOSFET gate threshold voltage and gate capacitance.
