Thermostat Digital Temperature Controller 220v AC PT100 K J Input TC4S TC4H TC4L TC4M PID Temp Control Thermoregulator 1300℃

This product is a TC4 series temperature controller with supply voltage of 85-265VAC 50/60Hz. The temperature controller is a relay and solid state relay SSR dual output type and is RTD, TC universal input which means that thermocouples such as K, J, PT100, etc. can be connected.Product parametersProduct ModelTC4 seriesSupply VoltageAC85-265V 50/60HzMeasurement Precision±0.5%FSTemperature Measurement RangeInput typesK,E, J, B, S, N, R, T, PT100, CU50 AvailableOutput typesElectromagnetic relay + SSRControl MethodON/OFF Position control , PID controlSampling period100msIndication method8-segment 4-digital display and LED indicationInsulation resistanceMin.100MQ(500VDC)MEGAPower consumptionMax.8VARelay OutputRelay contact output 250VAC 5A 1NO1NCSSR OutputSSR12VDC±2V Below 20mADielectric strength2000VAC 50/60Hz for 1min.( between all terminals and case)Memory retentionApprox.10years(non-volatile semiconductor memory type)Ambient temp.-5~40 storage:-10~50Ambient humi.35%~85%RH storage:35~85%RHAlarm Quantity1pcsUsage : IndustrialOrigin : Mainland ChinaFeature 1 : ThermostatFeature 2 : temperature controllerFeature 3 : digital temperature controllerFeature 4 : digital thermostatFeature 5 : pid temperature controllerSupply Voltage : 85-265vac
