Intellinet 9-Port Fast Ethernet PoE+ Switch, 8X 10/100 PoE+ Ports (140W Budget) + 1x Gigabit Uplink, Fanless Metal Desktop Network Switch - 560764

The Intellinet 8-Port Fast Ethernet PoE+ Switch (560764) is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with eight Fast Ethernet ports (all of which support 802.3at/af PoE/PoE+), this switch can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 100 Mbps.

• 8 PoE/PoE+ output ports for edge devices: Powers and connects up to eight IEEE 802.3af/802.3at devices such as access points, VoIP phones, and IP cameras over standard Ethernet cabling.
• 140 W total PoE budget: Provides up to 140 watts of shared PoE power across the eight PoE ports (150 W max unit consumption), suitable for mixed low- and mid-power endpoints.
• Gigabit uplink for the network connection: Includes one RJ45 Gigabit uplink port (IEEE 802.3ab) to reduce uplink bottlenecks when multiple PoE devices are active.
• Automatic port configuration and protection: 10/100 auto-sensing on Ethernet ports, Auto‑MDIX on all RJ45 ports, plus PoE device detection with short-circuit, overload, and high-voltage protection.
• Quiet, compact metal switch for desktop installs: Fanless design for silent operation, store-and-forward switching with IEEE 802.3x flow control, 2K MAC address table, and IEEE 802.3az energy-efficient Ethernet support in a desktop-size metal enclosure.
