Hollow Rotating Platform Ratio 5-200:1 4 Axis/ 5 Axis/R Axis High Precision,eplace Cam Indexer/DD Motor for Cutting Tables CNC

1 X Hollow Rotating Platform1 X Photoelectric sensorProduct Features:1. The rotary table of the hollow rotary platform is of hollow structure, and the motor is connected at the side to facilitate the installation of air pipes and wires in the smelting tool. Like the divider and DD motor, it can directly fix the heavy objects on the platform for transmission.2. Considering the side force and other problems when the product is used, we adopt cross roller bearing, and an anti overturning stable ring is set in the middle. In order to better withstand the lateral force load in use.3. The body is made of aluminum alloy and processed by high-precision CNC to ensure the accuracy of all parts. The gear adopts the carburizing heat treatment and grinding process, which can reach the gear accuracy of grade 5 after machining, and its surface hardness can reach 58-62HRC. After the assembly of the product is completed, -- lapping procedures will be carried out to ensure that the parallelism and perpendicularity of the end face are within a trace of runout.4. The accuracy level of some gears of the hollow rotating platform is up to 4, which makes the hollow rotating platform have very small air return. We can compensate for the error during assembly by designing the adjustable gear center distance, and the repeated positioning accuracy can reach less than 10 arc seconds.5. The worktable and mechanical arm of the device can be directly installed on the turntable of the hollow rotary platform. Compared with the use of mechanism parts such as pulley, it can reduce the working hours and costs of mechanism design, parts deployment, belt state adjustment, etc.Origin : Mainland ChinaModel Number : TST85Model number : TS085Speed Ratio : 5:1/10:1Positioning accuracy : 3arc-minOutput torque : 3 Times rated torqueload : 20/28kgRated output torque : 28N.mMax Output torque : 3 Times rated torqueProtection level : 50IPAllowable axial load : 500Suitable for stepping motor : 57 Stepper MotorAdapt to servomotor : 60 Servo MotorTorsional rigidity : 6N.m/arcminProduct type 1 : gearbox 85mmProduct type 2 : bevel gearboxProduct type 3 : gearbox nema23Product type 4 : gearboxProduct type 5 : planetary gearboxProduct type 6 : rotating platformProduct type 7 : hollow rotating platformProduct type 8 : right angle gearbox

• Wide Speed Ratio Range:Offers a versatile speed ratio of 5 1 to 200 1, catering to various CNC cutting table applications.
• Advanced Protection:Equipped with a 50IP protection level, this rotary table withstands harsh environments and heavy loads.
• Robust Construction:Crafted from aluminum alloy and processed by CNC, ensuring high-precision and durability for long-term use.
• Versatile Rotary Platform:Hollow rotating platform design allows for easy installation of air pipes and wires, ideal for smelting tools.
• High Precision Gearbox:Features a carburized, high-precision gearbox with a grade 5 accuracy and a hardness of 58-62HRC for reliable performance.
