DIN Rail Mount Flat Ribbon Cable 0.1" FRC Connector Interface Module, Terminal Block Breakout Board (IDC64 2x32Pin)
4.1 (44 items)
Limited Time Sale$24.60 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211033319 | Release Date | 2026/04/04 | List Price | $16.40 | Model Number | 211033319 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
IDC Male header connector, pin pitch 0.1" / 2.54mm. Terminal block: Wire range - 26-16AWG. Strip length - 5mm. Screws - M2,steel,Cr3+ Zn plated. Torque - 0.2Nm (1.7Lb-In.). Pin header and Cage - Brass. Rated voltage: 60V. Rated current: 1A / per pin. Operating temperature: -20 to 50 Celsius. FR-4 fiber glass PCB, dual copper layers. High quality fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm / 32mm / 15mm rail, and the carrier can be taken apart for PCB screw mount use.Datasheet: https://images-na.ssl-images-amazon.com/images/I/A1UVn9hNcBL.pdf
- IDC Male header connector, pin pitch 0.1" / 2.54mm.
- Terminal block: Wire range - 26-16AWG. Strip length - 5mm. Screws - M2,steel,Cr3+ Zn plated. Torque - 0.2Nm (1.7Lb-In.). Pin header and Cage - Brass.
- Rated voltage: 60V. Rated current: 1A / per pin. Operating temperature: -20 to 50 Celsius.
- High quality fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm / 32mm / 15mm rail, and the carrier can be taken apart for PCB screw mount use.
- Datasheet: https://images-na.ssl-images-amazon.com/images/I/A1UVn9hNcBL.pdf
| Color | Green |
|---|---|
| Gauge | 16.0 |
| Model | 6921407349049 |
| Pitch | 2.54 Millimeters |
| Voltage | 60 Volts |
| Brand Name | Electronics-Salon |
| Part Number | MD-D227T-1 |
| Manufacturer | Electronics-Salon |
| Material Type | Copper |
| Mounting Type | DIN Rail Mount |
| Connector Type | IDC |
| Current Rating | 1 Amps |
| Number Of Poles | 64 |
| Number Of Contacts | 64 |
| Number of Positions | 64 |
| Upper Temperature Rating | 50 Degrees Celsius |
