10PCS Industrial Control Electrical Relays CR-MX024DC2L with Relay Socket CR-M2SFBN Current Protection Relay

10PCS Industrial Control Electrical Relays CR-MX024DC2L With Relay Socket CR-M2SFBN Current Protection Relayintermediate relayCR-MX024DC2L ( 2 open 2 closed)Product series: CR-MXModel: CR-MX024DC2LConfiguration base model: CR-M2SFBN (sold separately)Number of contacts: 2c/o (SPDT) contactsContact form: 2 open 2 closedContact material: silver alloyContact rated current: 7ACoil mode: coilCoil voltage: DC24VCoil power: 0.9WCoil resistance: 650Weight: 35gInstallation size: 21.5mmX28mmX35mmProduct description:In electrical control, pluggable intermediate interface relays are typically used for electrical isolation, drive amplification, and signal matching, such as between a , PC, or fieldbus system and a sensor/actuator layer in the field. CR-MX series intermediate interface relays are more suitable for the practical needs of general industrial control. They are easy to install and debug, stable and reliable, and have a long service life.Characteristics:Standard miniature relay7 different rated line voltages: 12V.24V, 48V.110VAC: 24V110V.230VOutput: 2c/o (SPDT) contact (7A) or 4c/o (SPDT) contact (5A)With or without LED (: green; AC: red)Contact material does not contain cadmiumOptional pluggable function moduleApplication:The interface relay is electromagnetic and is mainly used between the control unit and the field device for electrical isolation, voltage matching, noise suppression and signal amplification.Operating mode:When the control voltage is applied to the relay coil, the output contact (NO) of the relay is pulled in; when the control voltage is lost, the output contact returns to the initial position.CR-MX plug-in intermediate interface relay==========Power : Theory : intermediate relayProtect Feature : SealedUsage : General PurposeContact Load : Low PowerModel Number : CR-MX024DC2L with CR-M2SFBNVoltage : 24VProduct series : CR-MXConfiguration base model : CR-M2SFBN (sold separately)Number of contacts : 2c/o (SPDT) contactsContact material : silver alloyContact rated current : 7ACoil mode : coilCoil voltage : DC24VCoil power : 0.9WWeight : 35gInstallation size : 21.5mmX28mmX35mm
